General data: | |
---|---|
Type: Attack | Crew: 2 |
Min Speed: 350 kt | Max Speed: 750 kt |
Wingspan: 17.6 m | Height: 6.2 m |
Length: 24.6 m | Max Payload: 8100 kg |
Empty Weight: 22320 kg | Max Weight: 39570 kg |
Operator: Air Force | Commissioned: 1990 |
Propulsion: 2x AL-21F-3A | Decommissioned: 2002 |
Sensors / EW: |
---|
Drop Kick [RPO Orion-A] - (Su-24M) Radar Radar, FCR, Air-to-Surface, Medium-Range Max Range: 148.2 km |
L-082 Mak-UL - (BKO-2 Karpaty EW Suite) Infrared MAWS, Missile Approach Warning System Max Range: 9.3 km |
SPS-162 Geran-F [L-102] - (Su-24M, BKO-2 Karpaty EW Suite) ECM DECM, Defensive ECM Max Range: 0 km |
Laser Designator [Kaira-24M] - (Su-24M) Laser Designator Laser Target Designator & Ranger (LTD/R) Max Range: 18.5 km |
Bomb Sight [Kaira-24M, LLTV] - (Su-24M) Visual Visual, Bomb Sight Max Range: 3.7 km |
SPO-15 Beryoza [L-006] - (Su-24M) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
TFR [Relyef] - (Su-24M) Radar TFR, Terrain Following Radar Max Range: 3.7 km |
Weapons / Loadouts: |
---|
AA-8 Aphid [R-60M] -
(1983) Guided Weapon Air Max: 9.3 km. |
AS-14 Kedge [Kh-29L] -
(1981) Guided Weapon Surface Max: 11.1 km. Land Max: 11.1 km. |
OFAB-100-120 Frag -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
FAB-250M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
FAB-500M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
RBK-250-PTAB CB [30 x PTAB-2.5 Anti-Tank Bomblets] -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
RBK-500-PTAB [268 x PTAB-1M Anti-Tank Bomblets] -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
S-5K 57mm Rocket -
(OOS ~2014, Superseded by S-8) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
S-8KO 80mm Rocket [HEAT] -
(1985) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
3000 liter Drop Tank -
Drop Tank |
OFAB-250-270 Frag -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
