| General data: | |
|---|---|
| Type: Attack | Crew: 1 |
| Min Speed: 300 kt | Max Speed: 570 kt |
| Wingspan: 8.4 m | Height: 4.6 m |
| Length: 12.2 m | Max Payload: 8318 kg |
| Empty Weight: 4460 kg | Max Weight: 11136 kg |
| Operator: Air Force | Commissioned: 1990 |
| Propulsion: 1x J52-P-8A | Decommissioned: 2001 |
| Sensors / EW: |
|---|
| AN/ALR-66(VE) - (Helicopter, A-7H) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| AN/APG-66Z - (Helicopter, A-7H) Radar Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range Max Range: 74.1 km |
| Weapons / Loadouts: |
|---|
| 300 USG Drop Tank -
Drop Tank |
| AIM-9L Sidewinder -
(1980) Guided Weapon Air Max: 18.5 km. |
| 400 USG Drop Tank -
Drop Tank |
| AGM-65B Maverick EO -
(1976) Guided Weapon Surface Max: 11.1 km. Land Max: 11.1 km. |
| AGM-65G Maverick IR -
(1991) Guided Weapon Surface Max: 14.8 km. Land Max: 14.8 km. |
| GBU-16B/B Paveway II LGB [Mk83] -
(USN) Guided Weapon Surface Max: 7.4 km. Land Max: 7.4 km. |
| CRV-7 C14 70mm Rocket -
(1976) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
| Mk82 500lb LDGP -
(1954) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| Mk83 1000lb LDGP -
(1954) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
