| General data: | |
|---|---|
| Type: Multirole (Fighter/Attack) | Crew: 2 |
| Min Speed: 350 kt | Max Speed: 920 kt |
| Wingspan: 9.5 m | Height: 4.8 m |
| Length: 15 m | Max Payload: 6894 kg |
| Empty Weight: 8715 kg | Max Weight: 19200 kg |
| Operator: Air Force | Commissioned: 2005 |
| Propulsion: 1x F100-PW-229 |
| Sensors / EW: |
|---|
| EL/L-8240 - ECM DECM, Defensive ECM Max Range: 0 km |
| AN/APG-68(V)9 - Radar Radar, FCR, Air-to-Air & Air-to-Surface, Medium-Range Max Range: 148.2 km |
| AN/ALR-56M - ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| Weapons / Loadouts: |
|---|
| 300 USG Drop Tank -
Drop Tank |
| 370 USG Drop Tank -
Drop Tank |
| 500 USG Conformal Tank -
Drop Tank |
| AIM-9S Sidewinder -
(1990) Guided Weapon Air Max: 18.5 km. |
| AIM-120C-5 AMRAAM P3I.2 -
(2003) Guided Weapon Air Max: 105 km. |
| Sharpshooter Pod [FLIR + LRMTS, 12k ft] -
(AN/AAQ-19) Sensor Pod |
| AGM-65B Maverick EO -
(1976) Guided Weapon Surface Max: 11.1 km. Land Max: 11.1 km. |
| AGM-88B HARM -
(1990) Guided Weapon Surface Max: 129.6 km. Land Max: 129.6 km. |
| GBU-12D/B Paveway II LGB [Mk82] -
Guided Weapon Surface Max: 7.4 km. Land Max: 7.4 km. |
| HYDRA 70mm Rocket -
(Mk 66 Rocket, M229 Warhead, M423/7 Fuze) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
| Mk20 Rockeye II CB [247 x Mk118 Dual Purpose Bomblets] -
(1969, Mk7 Dispenser) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| Mk82 500lb LDGP -
(1954) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| Mk84 2000lb LDGP -
(1955) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
