General data:
Type: Recon Crew: 2
Min Speed: 120 kt Max Speed: 245 kt
Wingspan: 14.6 m Height: 3.9 m
Length: 12.5 m Max Payload: 0 kg
Empty Weight: 5467 kg Max Weight: 8214 kg
Operator: Army Commissioned: 1990
Propulsion: 2x T53-L-701A Decommissioned: 1995
Sensors / EW:
AN/APR-44 - (Continuous-Wave RWR) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/ALQ-136(V)2 - (Pulse-Radar Jammer) ECM
DECM, Defensive ECM
Max Range: 0 km
AN/ALQ-147 Hot Brick - (Pulse-Radar Jammer) ECM
IRCM
Max Range: 0 km
AN/APR-32(V)2 - (Pulse-Radar RWR) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
KA-30 Panoramic Camera - (Pulse-Radar RWR) Visual
Visual, Reconnaissance Frame Camera
Max Range: 9.3 km
KA-60 Panoramic Camera - (Pulse-Radar RWR) Visual
Visual, Reconnaissance Frame Camera
Max Range: 9.3 km
KA-76 Serial Frame Camera - (Pulse-Radar RWR) Visual
Visual, Reconnaissance Frame Camera
Max Range: 9.3 km
AN/ALQ-162 Shadowbox - (Continuous-Wave-Radar Jammer) ECM
DECM, Defensive ECM
Max Range: 0 km
Weapons / Loadouts:
AN/APS-94F Recon Pod [SLAR] - Sensor Pod
