General data:
Type: FFG - Guided Missile Frigate Max Speed: 30 kt
Crew: 154 Length: 122.3 m
Beam: 14.4 m Draft: 4.3 m
Displacement Full: 3320 t Displacement: 2800 t
Operator: Navy Commissioned: 1994
Propulsion: 2x Stork-Wärtsilä 12 SWD 280 V-12 Cruise Diesels, 2x Rolls-Royce Spey RM-1A Gas Turbines, CODOG
Sensors / EW:
Telegon 4 - (AK 1200) ESM
HF/DF
Max Range: 926 km
SMART-S - (AK 1200) Radar
Radar, Air & Surface Search, 3D Medium-Range
Max Range: 148.2 km
AR-700A(V)1 APECS II - (ASP-2000) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
LW.08 - (RAWL-2, LAR-2, Type 1022, SPQ-502) Radar
Radar, Air Search, 2D Long-Range
Max Range: 333.4 km
ZW.06 - (1972, PIN 515) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
PHS-36 - (1972, PIN 515) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 7.4 km
AR-700A(V)1 - (ASP-2000, Assoc w APECS II) ESM
ELINT
Max Range: 926 km
DSBV 62C - (Anaconda) TASS, Passive-Only Towed Array Sonar System
TASS, Passive-Only Towed Array Sonar System
Max Range: 74.1 km
STIR 180 [Radar] - (Sea Sparrow) Radar
Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range
Max Range: 59.3 km
STIR 180 [IR Camera] - (Sea Sparrow) Infrared
Infrared, Target Tracking and Identification Camera
Max Range: 185.2 km
STIR 180 [TV Camera] - (Sea Sparrow) Visual
Visual, Target Tracking and Identification TV Camera
Max Range: 185.2 km
Weapons:
20mm/70 Oerlikon Mk7 Burst [20 rnds] - Gun
Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km.
30mm Goalkeeper Burst [240 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km.
Mk182 SRBOC Chaff [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
Mk186 TORCH Flare [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
RGM-84D Harpoon IC - (1986) Guided Weapon
Surface Max: 138.9 km.
RIM-7M Sea Sparrow - (1985) Guided Weapon
Air Max: 25.9 km. Surface Max: 25.9 km.
AN/SLQ-25 Nixie - Decoy (Towed)
Surface Max: 1.9 km.
Mk46 NEARTIP Mod 5 - (1984) Torpedo
Subsurface Max: 7.4 km.
76mm/62 Mk100 HE Burst [4 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
