| General data: | |
|---|---|
| Type: FFG - Guided Missile Frigate | Max Speed: 26 kt |
| Crew: 200 | Length: 103.2 m |
| Beam: 10.8 m | Draft: 3.1 m |
| Displacement Full: 1960 t | Displacement: 1565 t |
| Operator: PLAN | Commissioned: 2011 |
| Propulsion: 2x 12E390VA Diesels |
| Sensors / EW: |
|---|
| China Type 726 Fin Curve [Decca 707 Copy] - Radar Radar, Surface Search & Navigation Max Range: 37 km |
| China Type 360 - (Sea Tiger, MR-36A(?), SR-60, S-3, Seagull-S) Radar Radar, Air & Surface Search, 2D Medium-Range Max Range: 250 km |
| China Type 352 Square Tie - (SSM, Rangout) Radar Radar, FCR, Surface-to-Surface Max Range: 74.1 km |
| China Type 343 Sun Visor [Radar] - (Group, 100mm FCS, Sun Visor / Wasp Head) Radar Radar, FCR, Weapon Director Max Range: 27.8 km |
| China Type 343 Wasp Head [Visual Director] - (Group, 100mm FCS, Sun Visor / Wasp Head) Visual Visual, Weapon Director TV Camera Max Range: 74.1 km |
| China Type 347G Rice Bowl - (37mm, EFR-1) Radar Radar, FCR, Weapon Director Max Range: 37 km |
| China H/SJD-5A [Tamir-11 Impr] - (Jianghu III, EH-5A, Echo Type 5) Hull Sonar, Active-Only Hull Sonar, Active-Only Search Max Range: 3.7 km |
| China Type 923-1 Jug Pair - (RW-23-1, Watch Dog) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| Weapons: |
|---|
| Depth Charge [Generic] -
Depth Charge Subsurface Max: 0.2 km. |
| China Type 81 ASW Rocket Salvo [5 rnds] -
(RBU-1200) Rocket Subsurface Max: 1.9 km. |
| 100mm/56 Twin PJ33A Frag Burst [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
| 100mm/56 Twin PJ33A HE [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
| YJ-83 [C-802A, CSS-N-8 Saccade] -
(1999) Guided Weapon Surface Max: 185.2 km. |
| 37mm/63 Twin Burst [20 rnds] -
Gun Air Max: 1.9 km. Surface Max: 2.8 km. |
| Generic RF Decoy Round -
(Early 2000s) Decoy (Expendable) Surface Max: 1.9 km. |
| Generic Chaff Rocket -
(Ship-only) Decoy (Expendable) Surface Max: 1.9 km. |
