General data:
Type: DDG - Guided Missile Destroyer Max Speed: 32 kt
Crew: 280 Length: 132 m
Beam: 12.8 m Draft: 4.4 m
Displacement Full: 3960 t Displacement: 3670 t
Operator: PLAN Commissioned: 1987
Propulsion: 2x Steam Turbines, 2x Boilers Decommissioned: 2007
Sensors / EW:
China Type 352 Square Tie - (SSM, Rangout) Radar
Radar, FCR, Surface-to-Surface
Max Range: 74.1 km
China Type 923-1 Jug Pair - (RW-23-1, Watch Dog) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
China Type 343 Sun Visor [Radar] - (Group, 100mm FCS, Sun Visor / Wasp Head) Radar
Radar, FCR, Weapon Director
Max Range: 27.8 km
China Type 343 Wasp Head [Visual Director] - (Group, 100mm FCS, Sun Visor / Wasp Head) Visual
Visual, Weapon Director TV Camera
Max Range: 74.1 km
China Type 726 Fin Curve [Decca 707 Copy] - (Group, 100mm FCS, Sun Visor / Wasp Head) Radar
Radar, Surface Search & Navigation
Max Range: 37 km
China Type 354 Eye Shield - (2D, MX-902) Radar
Radar, Air & Surface Search, 3D Medium-Range
Max Range: 185.2 km
China Type 341 Rice Lamp - (37mm) Radar
Radar, FCR, Weapon Director
Max Range: 37 km
China Type 517 Knife Rest - (Pea Sticks) Radar
Radar, Air Search, 2D Medium-Range
Max Range: 203.7 km
China H/SJD-1 - (Luda I) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search
Max Range: 11.1 km
China H/SJD-N - (Luda I, Type 675) Hull Sonar, Active-Only
Hull Sonar, Active-Only Mortar Fire Control
Max Range: 3.7 km
Weapons:
FQF-2500 Anti-Torpedo Depth Charge Salvo [12 rnds] - Depth Charge
Subsurface Max: 1.9 km.
25mm/60 Type 61 Twin Burst [20 rnds] - Gun
Air Max: 1.5 km. Surface Max: 2.8 km. Land Max: 2.8 km.
130mm/58 Twin SAP Burst [2 rnds] - Gun
Surface Max: 18.5 km. Land Max: 18.5 km.
130mm/58 Twin HE Burst [2 rnds] - Gun
Air Max: 3.3 km. Surface Max: 18.5 km. Land Max: 18.5 km.
HY-1J [CSS-N-2 Safflower, Ship] - (1979) Guided Weapon
Surface Max: 129.6 km.
37mm/63 Twin Burst [20 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km.
