General data:
Type: FFL - Corvette Max Speed: 32 kt
Crew: 30 Length: 50.5 m
Beam: 7.5 m Draft: 2 m
Displacement Full: 335 t Displacement: 310 t
Operator: Navy Commissioned: 1994
Propulsion: 2x MTU 16V 396 TB94 Diesels, 1x Vericor TF50 Gas Turbine, CODAG
Sensors / EW:
PN-621 [Scanter] - (1985) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
PS-751 & PS 726 [Sea Giraffe 50 HC & ArtE 726E Surveillance] - (1984) Radar
Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface
Max Range: 55.6 km
TSM 2642 Salmon - (1984) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 7.4 km
SA 950 - (Elma attack sonar) Hull Sonar, Active-Only
Hull Sonar, Active-Only Mine Hunting & ASW Mortar Fire Control [Detection & Classification]
Max Range: 1.1 km
PQ-872 [AR-700A(V)1 Phoenix II] - (ASP-2000, Assoc w PQ 844) ESM
ELINT
Max Range: 926 km
CEROS 200 Tracker [9LV Mk3 Basic] - (Group, PE 723 Radar, 9GR400) Radar
Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range
Max Range: 46.3 km
EOS 500 [CCD] - (Group, PE 723 Radar, 9GR400) Visual
LLTV, Weapon Director
Max Range: 185.2 km
EOS 500 [IR Camera] - (Group, PE 723 Radar, 9GR400) Infrared
Infrared, Weapon Director Camera
Max Range: 185.2 km
EOS 500 [Laser Rangefinder] - (Group, PE 723 Radar, 9GR400) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
PQ-844 - (Assoc w PQ 868, PQ 872) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
Weapons:
Philax Chaff - Decoy (Expendable)
Surface Max: 1.9 km.
Philax Flare - Decoy (Expendable)
Surface Max: 1.9 km.
Elma ASW-600 ASW Mortar Salvo [M90 Hard Kill DC, 9 rnds] - (1993) Gun
Subsurface Max: 0.6 km.
57mm/70 Bofors Mk2 GP Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 9.3 km. Land Max: 9.3 km.
40mm/70 Single Bofors Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
RB 15M Mk1 - (1987) Guided Weapon
Surface Max: 83.3 km.
Tp 613 - (1985, Surface, Anti-Ship) Torpedo
Surface Max: 22.2 km.
