| General data: | |
|---|---|
| Type: SSN - Nuclear Powered Attack Submarine | Max Depth: -400 m |
| Commissioned: 2012 | Length: 107 m |
| Beam: 11 m | Draft: 7.5 m |
| Crew: 100 | Displacement: 6000 t |
| Propulsion: 1x Nuclear Reactor | Max Speed: 30 kt |
| Sensors / EW: |
|---|
| China Type 921-A Golf Ball - (Submarine, Stop Light) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| China SQC-207 - (Shang, Jin, Flank Sonar) Hull Sonar, Passive-Only Hull Sonar, Passive-Only Ranging Flank Array Search & Track Max Range: 74.1 km |
| TSM 2255 - (DUUX 5, Assoc w Eledone & Sculla) Hull Sonar, Passive-Only Hull Sonar, Passive-Only Ranging Flank Array Search & Track Max Range: 74.1 km |
| TSM 2233 Eledone [DSUV 2H + DUUA 2D] - (DSUV 22 System = DSUV 2H + DUUA 2D) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 74.1 km |
| China H/LQK-359A - (Type 359) Radar Radar, Surface Search, Short-Range Max Range: 37 km |
| TSM 2243 - (DUUG-5, Assoc w/ DSUV 22/TSM 2233) Acoustic Intercept (Active Sonar Warning) Acoustic Intercept Max Range: 66.7 km |
| China SJG-206A TASS - (Submarine) TASS, Passive-Only Towed Array Sonar System TASS, Passive-Only Towed Array Sonar System Max Range: 129.6 km |
| Generic Submarine Periscope, LLTV - (2000s/2010s, Gen 3, 1.5x/8x Zoom) Visual LLTV, Surveillance & Navigation Camera Max Range: 41.7 km |
| Generic Submarine Periscope, Optical - (2010s, 1.5x/12x Zoom) Visual Visual, Surveillance Periscope Max Range: 41.7 km |
| Weapons: |
|---|
| Generic Acoustic Decoy -
(2000s, Noisemaker / Bubble Screen) Decoy (Expendable) Subsurface Max: 1.9 km. |
| Yu-6 -
(2006, ASW & ASuW, Submarine) Torpedo Surface Max: 11.1 km. Subsurface Max: 11.1 km. |
| CSS-N-4 Sardine [YJ-82] -
(China, 1998, C-801Q, Sub-Launched) Guided Weapon Surface Max: 129.6 km. |
