| General data: | |
|---|---|
| Type: SSK - Hunter-Killer Submarine | Max Depth: -250 m |
| Commissioned: 2022 | Length: 89.5 m |
| Beam: 9.6 m | Draft: 7.62 m |
| Crew: 50 | Displacement: 3358 t |
| Propulsion: 4x PH1 PEM Fuel Cells | Max Speed: 20 kt |
| Sensors / EW: |
|---|
| SERO 400 TV/EO Component - (1.5x/12x Zoom) Visual Visual, Surveillance & Navigation TV Camera Max Range: 41.7 km |
| SERO 400 LLTV Component - (2000s/2010s, 1.5x/12x Zoom) Visual LLTV, Surveillance & Navigation Camera Max Range: 41.7 km |
| SERO 400 IR Component - (1x/4x Zoom) Infrared Infrared, Surveillance & Navigation Camera Max Range: 27.8 km |
| OMS 100 IR Component [QLR] - (1x/2x Zoom) Infrared Infrared, Day/Night Spherical Situational Awareness & Fire Control Max Range: 27.8 km |
| Series 30 SMS TV/EO Component - (1.5x/24x Zoom) Visual Visual, Surveillance & Navigation TV Camera Max Range: 41.7 km |
| Series 30 SMS LLTV Component - (2000s/2010s, 1.5x/24x Zoom) Visual LLTV, Surveillance & Navigation Camera Max Range: 41.7 km |
| Series 30 SMS IR Component - (2000s/2010s, 1.5x/12x Zoom) Infrared Infrared, Surveillance & Navigation Camera Max Range: 41.7 km |
| Series 30 SMS QLR IR Component - (1x/2x Zoom) Infrared Infrared, Day/Night Spherical Situational Awareness & Fire Control Max Range: 27.8 km |
| Sphynx - (1x/2x Zoom) Radar Radar, Surface Search & Navigation Max Range: 37 km |
| Pegaso RESM - (KSS-III, Upgraded) ESM ELINT w/ OTH Targeting Max Range: 926 km |
| MOAS - (Thales) Hull Sonar, Active-Only Hull Sonar, Active-Only Shallow Water High-Definition Mine & Obstacle Avoidance Max Range: 0.9 km |
| KSS-3 Hull Sonar - (LIG Nex1) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 44.4 km |
| KSS-3 Flank Array - (LIG Nex1) Hull Sonar, Passive-Only Hull Sonar, Passive-Only Ranging Flank Array Search & Track Max Range: 74.1 km |
| KSS-3 Intercept Array - (LIG Nex1) Acoustic Intercept (Active Sonar Warning) Acoustic Intercept Max Range: 127.8 km |
| KSS-3 TASS - (LIG Nex1) TASS, Passive-Only Towed Array Sonar System TASS, Passive-Only Thin Line Towed Array Sonar System Max Range: 74.1 km |
| Weapons: |
|---|
| Tiger Shark -
(2020) Torpedo Surface Max: 50 km. Subsurface Max: 50 km. |
| White Shark -
(South Korea, 2002, K731, ASW & ASuW) Torpedo Surface Max: 9.3 km. Subsurface Max: 9.3 km. |
| UGM-84L Harpoon II -
Guided Weapon Surface Max: 138.9 km. Land Max: 138.9 km. |
| Hyunmoo 3A -
(South Korea, Not deployed?) Guided Weapon Land Max: 1018.6 km. |
| Hyunmoo 3B -
(South Korea, 2008) Guided Weapon Land Max: 1018.6 km. |
| Hyunmoo 3C -
(South Korea, 2015, Xuanwu 3) Guided Weapon Land Max: 1481.6 km. |
| Hyunmoo 2B [NHK-2 PIP-B] -
(2010) Guided Weapon Land Max: 500 km. |
| CIRCE Torpedo Jammer -
(C303/S, C310, TAU, Submarine) Decoy (Expendable) Subsurface Max: 1.9 km. |
| CIRCE Torpedo Decoy -
(C303/S, C310, TAU, Submarine) Decoy (Expendable) Subsurface Max: 1.9 km. |
