General data:
Type: DDG - Guided Missile Destroyer	Max Speed: 30 kt
Crew: 274	Length: 119.2 m
Beam: 12.5 m	Draft: 5.7 m
Displacement Full: 3460 t	Displacement: 2615 t
Operator: Navy	Commissioned: 1990
Propulsion: 4x Boilers, 2x General Electric Steam Turbines	Decommissioned: 2003

Sensors / EW:
W-160 - Radar Radar, Air & Surface Search, 3D Short-Range Max Range: 74.1 km
DA.08/1 - (Single Beam, PFN 513, AN/SPQ-50) Radar Radar, Air & Surface Search, 2D Medium-Range Max Range: 185.2 km
AN/SQS-23 [DE 1191 Upgrade] - (Single Beam, PFN 513, AN/SPQ-50) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Attack Max Range: 37 km
AN/SPS-10B - (Single Beam, PFN 513, AN/SPQ-50) Radar Radar, Surface Search & Navigation Max Range: 74.1 km
Chang Feng III [ESM] - (Wu Chin III, AR-680) ESM ELINT Max Range: 926 km
Chang Feng III [ECM] - (Wu Chin III, Protector, MEWS, SLQ-31) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km
STIR 180 [Radar] - (SM-1) Radar Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range Max Range: 59.3 km
LIOD Mk.1 [Optronic] - (Group) Visual Visual, Weapon Director TV Camera Max Range: 74.1 km

Weapons:
RIM-66A SM-1MR Blk IV - (1969, Main Production Variant) Guided Weapon Air Max: 33.3 km. Surface Max: 33.3 km.
T Mk 6 Fanfare - Decoy (Towed) Surface Max: 1.9 km.
RUR-5A Mod 4 ASROC RTT [Mk46 Mod 2] - Guided Weapon Subsurface Max: 18.5 km.
40mm/70 Single Bofors Burst [4 rnds] - Gun Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
20mm/85 Mk15 Phalanx Blk 1 Burst [300 rnds] - Gun Air Max: 1.5 km.
76mm/62 Compact HE Burst [4 rnds] - Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
12.7mm/50 MG Burst [10 rnds] - (Facility/Ship, No Anti-Air Capability) Gun Surface Max: 1.9 km. Land Max: 1.9 km.
Mk46 NEARTIP Mod 5 - (1984) Torpedo Subsurface Max: 7.4 km.
Kung Fen Chaff - Decoy (Expendable) Surface Max: 1.9 km.
Hsiung Feng II - Guided Weapon Surface Max: 111.1 km.
